OEM Factory for Decoiler And Recoiler - Roof Ridge Cap Roll Forming Machine – Haixing Industrial Detail:

Roof ridge cap roll forming machine parameters

1 Decoiler Manual decoiler or hydraulic decoiler
2 Raw material thickness 0.2-0.8mm
3 Material As your requirements
4 Machine dimensions 7000*800*1500mm
5 Feeding width According to your profile
6 Forming station 13 to 15 steps
7 Shaft diameter 75mm
8 Shaft material High-grade 45# steel, heated and quenched
9 Roller material High-grade 45# steel, coated with 0.05mm chrome
10 Forming speed 10-15m/minute (adjustable)
11 Transmission type Chain transmission
12 Machine frame stand Welded structural steel, thickness is 18mm
13 Main motor 5.5kW from Shanghai, China
14 Cutting type Stop hydraulic cutting
15 Cutting power 3kW
16 Cutter material Cr12 with quenched treatment HRC 58-62
17 Cutting length error ±2mm
18 Voltage 380V/50Hz and 3 or according to your requirements
19 Control system PLC control system
20 Size of PLC 700*1000*300mm
21 PLC Delta/Siemens

The color steel ridge tiles and aluminum-formed ridge tiles that are pressed out of roof ridge cap roll forming machine are lighter, easier to install and less expensive.

Machine details:

Ridge cap machine41 Ridge cap machine42 Ridge cap machine43

Package and shipment details:

The machines sold by Haixing Industrial Group Co., Ltd. use standard export packaging, as follows:
1*40GP container,main machine naked and fastened with iron wire in the container, rollers were painted with oil and packed with plastic film, electrics devices be packed with wooden box.
