Supply OEM/ODM Chian Drive Garage Door Frame Forming Machine

Short Description:

The steel door frame roll forming machine is a complete product line. After roll forming by our production line, we could make very smooth and beautiful steel door frame without any scratch on surface.


Product Detail

Product Tags

abide by the contract”, conforms towards the market requirement, joins during the market competition by its premium quality too as provides extra comprehensive and fantastic company for customers to let them develop into significant winner. The pursue of the organization, is definitely the clients’ fulfillment for Supply OEM/ODM Chian Drive Garage Door Frame Forming Machine, We feel we will become a leader in developing and producing good quality products and solutions in the two Chinese and international markets. We hope to cooperate with more pals for mutual advantages.
abide by the contract”, conforms towards the market requirement, joins during the market competition by its premium quality too as provides extra comprehensive and fantastic company for customers to let them develop into significant winner. The pursue of the organization, is definitely the clients’ fulfillment for Door Frame Roll Forming Machine, Roll Forming Machine, Steel Door Frame Roll Forming Machine, We rely on high-quality materials, perfect design, excellent customer service and the competitive price to win the trust of many customers at home and abroad. 95%products are exported to overseas markets.

Steel profile door frame roll forming machine parameters

1 Material width 3 sizes. Waiting for buyer exactly profile
2 How to adjust size Option : by PLC (It can be adjust by PLC and also in hand wheel)
One side fixed and the other is adjustable by manual or PLC
3 Base frame base frame 30 mm thick steel plate process the surface on CNC planer to keep it leveling and drill bolts and key slot by CNC
4 Rolling Speed 12-15m/min(not include cutting time)
5 Rolling Thickness 1.2-2.0mm
6 Material GI or metal
7 Control System PLC  (Panasonic) as list in the note
8 decoiler 3 Ton manual decoiler
9 Leveling Up in 3 roller, down in 4 roller
10 Roller Stations About 20 stations
11 Roller Material Gcr15, coated with chrome HRC58-62 degree
12 Shaft Material and DIA ¢70mm, material is 45# forge steel
13 Maim Motor Power 11kw brake motor
14 Hydraulic Station Power 5.5kw
15 Hydraulic Pressure 20Mpa
16 Capacity of tonnage for punching 22Tons
17 Hydraulic pump brand Lichao
18 Cutting Hydraulic post-cutting for cut end product
19 Extra cutter One more cutter for each profile
20 Material Of Cutting Cr12Mov quenching 58-62ºC
21 Electric Source 380V, 60HZ,3 phase
22 Way Of Drive 1.2 inch single chain
23 Color Of The Machine Yellow and blue
24 Machine Type Iron Cast
25 Emergency switch In main machine and control panel all have emergency switch for forbid any urgently accident.
26 Protect cover Complete mobile safety cover from roll forming to the cutter.
27 Size of the machine L*W*H   12m*1.2m*1.2m
28 Container Need 1 x40 feet (base on final)

The steel door frame roll forming machine is a complete product line. After roll forming by our production line, we could make very smooth and beautiful steel door frame without any scratch on surface.

Machine picture display

Steel Profile Door Frame Roll Forming Machine1 Steel Profile Door Frame Roll Forming Machine2

Packaging Details

1. Machine is covered by plastic film.

2. PLC control box, spare parts and other small parts are packed by wooden carton box.

Terms:

1. Delivery: within 60 days after receiving the deposit.

2. Package: export standard package for container.

3. Payment: TT (30% by TT in advance, 70% by TT after inspect the machine before delivery).
