Trapezoidal Sheet Roll Forming Machine

Short Description:


  • FOB Price: Get Latest Price from inquiry
  • Min.Order Quantity: 1 set
  • Supply Ability: 200 sets per Month
  • Port: TIANJIN
  • Payment Terms: L/C,D/A,D/P,T/T,Western Union,Money Gram payments for offline orders.
  • Lead Time: 25-35 days after received the deposit
  • Product Detail

    Product Tags

    Trapezoidal Sheet Roll Forming Machine parameters

    1 Main motor power 4kW, 3-phase or as your requests
    2 Hydraulic motor power 3kW
    3 Hydraulic pressure 10-12MPa
    4 Voltage 380V/3-phase/50Hz (or as your requirements)
    5 Control system PLC delta inverter
    6 Mainframe 300/350mm H-beam or 350mm
    7 Backboard thickness 16mm
    8 Chain size 1 Inch
    9 Feeding material color steel coils
    10 Feeding thickness 0.3-0.8mm
    11 Feeding width 1000mm
    12 Effective width 850mm
    13 Productivity 0-15/min
    14 Roll station 13 roll steps (according to different design)
    15 Roller diameter 70mm (depends on different design)
    16 Roller material 45# steel
    17 Cutter material Cr12
    18 Cr-plating size 0.05mm
    19 Overall size 6800*1400*1150mm
    20 Total weight 4.8 tons

    The application of metal roof sheets for house and villas:



    It can produce several of steel roof and wall panel, the products are widely used as the roof and wall of factory, warehouse, garage, gymnasium, exhibition center, cinema, theatre, etc.

    Detail of machine:

    Trapezoidal Sheet Roll Forming Machine11 Trapezoidal Sheet Roll Forming Machine21

    Packaging Details

    1. Machine is covered by plastic film.

    2. PLC control box, spare parts and other small parts are packed by wooden carton box.
