Our eternal pursuits are the attitude of “regard the market, regard the custom, regard the science” along with the theory of “quality the basic, have confidence in the first and administration the advanced” for 100% Original Light steel main channel making iron door frame forming machinery, Only for accomplish the good-quality product or service to satisfy customer’s demand, all of our products have been strictly inspected before shipment.
Our eternal pursuits are the attitude of “regard the market, regard the custom, regard the science” along with the theory of “quality the basic, have confidence in the first and administration the advanced” for , We insist on “Quality First, Reputation First and Customer First”. We’re committed to providing high-quality goods and good after-sales services. Up to now, our merchandise have been exported to more than 60 countries and areas around the world, such as America, Australia and Europe. We enjoy a high reputation at home and abroad. Always persisting in the principle of “Credit, Customer and Quality”, we expect cooperation with people in all walks of life for mutual benefits.
|
Steel profile door frame roll forming machine parameters |
||
| 1 | Material width | 3 sizes. Waiting for buyer exactly profile |
| 2 | How to adjust size | Option : by PLC (It can be adjust by PLC and also in hand wheel) One side fixed and the other is adjustable by manual or PLC |
| 3 | Base frame | base frame 30 mm thick steel plate process the surface on CNC planer to keep it leveling and drill bolts and key slot by CNC |
| 4 | Rolling Speed | 12-15m/min(not include cutting time) |
| 5 | Rolling Thickness | 1.2-2.0mm |
| 6 | Material | GI or metal |
| 7 | Control System | PLC (Panasonic) as list in the note |
| 8 | decoiler | 3 Ton manual decoiler |
| 9 | Leveling | Up in 3 roller, down in 4 roller |
| 10 | Roller Stations | About 20 stations |
| 11 | Roller Material | Gcr15, coated with chrome HRC58-62 degree |
| 12 | Shaft Material and DIA | ¢70mm, material is 45# forge steel |
| 13 | Maim Motor Power | 11kw brake motor |
| 14 | Hydraulic Station Power | 5.5kw |
| 15 | Hydraulic Pressure | 20Mpa |
| 16 | Capacity of tonnage for punching | 22Tons |
| 17 | Hydraulic pump brand | Lichao |
| 18 | Cutting | Hydraulic post-cutting for cut end product |
| 19 | Extra cutter | One more cutter for each profile |
| 20 | Material Of Cutting | Cr12Mov quenching 58-62ºC |
| 21 | Electric Source | 380V, 60HZ,3 phase |
| 22 | Way Of Drive | 1.2 inch single chain |
| 23 | Color Of The Machine | Yellow and blue |
| 24 | Machine Type | Iron Cast |
| 25 | Emergency switch | In main machine and control panel all have emergency switch for forbid any urgently accident. |
| 26 | Protect cover | Complete mobile safety cover from roll forming to the cutter. |
| 27 | Size of the machine | L*W*H 12m*1.2m*1.2m |
| 28 | Container Need | 1 x40 feet (base on final) |
The steel door frame roll forming machine is a complete product line. After roll forming by our production line, we could make very smooth and beautiful steel door frame without any scratch on surface.
Machine picture display
Packaging Details：
1. Machine is covered by plastic film.
2. PLC control box, spare parts and other small parts are packed by wooden carton box.
Terms:
1. Delivery: within 60 days after receiving the deposit.
2. Package: export standard package for container.
3. Payment: TT (30% by TT in advance, 70% by TT after inspect the machine before delivery).
