China Factory for Electric Decoiler For 10 Ton - Rock Wool Sandwich Sheet Production Line – Haixing Industrial

Rock Wool Sandwich Sheet Production Line parameters

1

Equipment overall dimensions

30m*2.6m*3m

2

Total weight

About 16 ton

3

Control system

Omron encoder PLC

4

Main motor power

Planetary cycloid reducer, 4kw, 380V, 50HZ

5

Processing speed

4~4.5 m/min, continuous stepless adjusted, variable frequency speed regulation, digital display

6

raw material

1.2 meters

7

Voltage

380V

8

Roller material

chrome plated on 45# steel forgings

9

Number of rubber shafts

27 foams, 39 rock wool

10

Total power

30 kw

11

Synchronous controller

Digital synchronous controller

12

Corrugated press motor power

Double-stage cycloid reducer 4kw, 380V, 50HZ

13

Application

roof panel, wall panel

Roll forming machine

1 set

Hydraulic cutter

1 set

Electrical control system

1 set

Hydraulic system

1 set

Normal stacker table

3 PC.

1m*1m

Manual decoiler

1 set.

Maximum load: 5T.
