Rock Wool Sandwich Sheet Production Line parameters |
||
|
1 |
Equipment overall dimensions |
30m*2.6m*3m |
|
2 |
Total weight |
About 16 ton |
|
3 |
Control system |
Omron encoder PLC |
|
4 |
Main motor power |
Planetary cycloid reducer, 4kw, 380V, 50HZ |
|
5 |
Processing speed |
4~4.5 m/min, continuous stepless adjusted, variable frequency speed regulation, digital display |
|
6 |
raw material |
1.2 meters |
|
7 |
Voltage |
380V |
|
8 |
Roller material |
chrome plated on 45# steel forgings |
|
9 |
Number of rubber shafts |
27 foams, 39 rock wool |
|
10 |
Total power |
30 kw |
|
11 |
Synchronous controller |
Digital synchronous controller |
|
12 |
Corrugated press motor power |
Double-stage cycloid reducer 4kw, 380V, 50HZ |
|
13 |
Application |
roof panel, wall panel |
Components of rock wool sandwich sheet production line:
|
Roll forming machine |
1 set |
|
Hydraulic cutter |
1 set |
|
Electrical control system |
1 set |
|
Hydraulic system |
1 set |
|
Normal stacker table |
3 PC. 1m*1m |
|
Manual decoiler |
1 set. Maximum load: 5T. |
Machine picture display
Roof advantages:
Waterproof, fireproof, antifreeze, corrosion resistant, compressive strength, light weight, beautiful, and environmentally friendly.
